KONTİNÜ DÖKÜM

ECMT-100

SPECIFICATION . Ecmt-100

Max.Output Capacity:

200~350kg/min(Continuous Type)

Mixer Total Power:

37kw

Max.Mixing Speed:

25006000r/min

Foaming Type:

Trough & Sprayer

Save Formular Q.T.Y.:

13 Groups.

Foaming Size:

W2300mm*H1200mm(Width Adjustable)

Control System:

PLC Digital Touch Screen(Made In TaiWan) And Electirc Control System.

PPG Tank:

5Ton*1Set.

POP Tank:

5Ton*1Set.

PPG+CACO3 Tank

5Ton*1Set

Fire-Retardard Tank

1Ton*1Set

 TDI Tank:

4Ton*1Set.



MC Tank:

1 Ton*1Set.

Silicone +Water Tanks:

180L*2Sets

T-9+Amine+Color (A.B.C):

180L*5Sets

Side Wall Size:

L18m*H1200mm

Fallplate:

L7m*W1.352.4m(Adjustable)

Foaming Platform:

L2900mm*W3000mm*H700mm

Conveyor Line:

L18m

Side/Bottom Paper Feed & Rewind System:

2Sets.

Walkway:

W500mm*L18m

Air Valves

Euro Standard

Chiller(Both Cooling & Heating System):

1Set*1.5HP(Made In TaiWan)

Side Film Lifting System:

1Set.

Foaming Density Range:

870kg/Cubicmeter.

Match With Block Cutter:

1Set.

Total Motor Power:

Approx 125kw.

Air Compressor:

Match With (11HP)*1Set

Machine N.W.:

Approx 25Ton

Floor Space Required:

L45m*W5m*H4.5m.
